The Power to Create...

Technical SpecificationsUJF-6042Mkll
Print head On-demand Piezo head
Ink type


LH-100 (C, M, Y, K, Lc, Lm, W, Cl)
LUS-120 (C, M, Y, K, Lc, Lm, W, Cl)
PR-200 (Primer)


Max print. size
Width 610mm x Length 420mm
Media weight Less than 8 kg
Interface USB 2.0
Dimensions (w x d x h)
1,665 mm × 1,290 mm × 856 mm
(65.6 in × 50.8 in × 33.7 in)
Weight (max.) 150 kg
Mimaki UJF-6042 MkII flatbed printer

 UJF-6042Mkll is advanced flatbed UV-curable inkjet printer that create high-value-added product, achieve superior productivity and print quality, and have a greater ability to accommodate a wide range of application.

  • Approximately 20% faster print speed than with conventional models.
  • Advanced mechanical structure improves value-added print products.
  • High-performance inks expand the range of applications, choice of LH-100 OR LUS-120 ink, with up to 9 colours including white, clear and primer.
  • Mimaki's unique print-quality management enhances color representation.
  • Maintenance functions ensure worry-free print operation.
  • Sophisticated RIP "RasterLink 6" software maximizes performance included.
  • Print on almost anything thanks to 153 mm head height.

Kebab Mk2
The Kebab option, "Kebab MkII" and "Kebab MkII L," enables printing on various cylindrical objects with length ranging from 300mm, in the case of "UJF-3042Mkll," to maximum 600mm, in the case of "UJF-6042Mkll." The option "Kebab Mkll L" can also be installed on “UJF-7151 plus.” Minimum and maximum diameter of cylindrical products range is from 10mm to 110mm, and it can includes wine and water bottles, seals, candles etc., making possible printing single on-demand original products.
